Descrizione
Rigid resin with superior stiffness and temperature resistance
Ultracur3D® RG 1100 from Forward AM is a high-strength polyurethane engineering-grade resin with mechanical properties comparable to popular injection molding grades used in the automotive and other demanding industries. Thanks to its high heat deflection temperature (HDT 116°C), good chemical resistance, and long-term UV stability, this material is ideally suited for applications such as automotive connectors, demanding engineering parts, exterior covers, brackets, and housings.
The advantages in brief
- Very high rigidity
- Impressive all-round temperature resistance
- High chemical resistance and low water absorption
Example applications
- Automotive connectors
- Challenging engineering parts
- External coverings
- Brackets and housings
Material properties
- Young's modulus: 3080 MPa
- Tensile strength: 70 MPa
- Heat deflection temperature: 116°C
- Water absorption (24 hours): 0.32%
TDS RG 1100 - TDS RG 1100 B
